| 性能规范 specifications |
|
|
|
| 公称压力 Nominal pressure |
PN |
1.6,2.5,4.0,6.4 |
Mpa |
| 强度试验压力 Strength testing pressure |
PT |
2.4,3.8,6.0,9.6 |
| 低压气密封试验压力 Seat testing pressure（low pressure） |
0.6 |
Mpa |
| 高压气密封试验压力 Seat testing pressure（high pressure |
1.8,2.8,4.4,7.1 |
| 适用介质 Applicable medium |
水、油、气WATER,oil，Gas |
硝酸类 Nitric acid |
醋酸类 Acetic acid |
| 适用温度Applicable temperature |
（-40~180℃） | |
| |
| 主要零件材料 Materials of main parts |
| 零件名称 Description of parts |
|
|
|
| 阀体 Body |
WCB |
ZG1Cr18Ni9TiCF8 |
ZG1Cr18Ni12Mo2TiCF8M |
| 球体 Ball |
1Cr18Ni9Ti304 |
1Cr18Ni9Ti304 |
1Cr18Ni12Mo2Ti316 |
| 阀杆 Stem |
1Cr18Ni9Ti304 |
1Cr18Ni9Ti304 |
1Cr18Ni12Mo2Ti316 |
| 密封圈Sealring |
聚四氟乙烯 Polyterafluoroethylene（PTFE) |
| 填料 Packing |
聚四氟乙烯 Polyterafluoroethylene（PTFE) | |
产品规格(Product specifications )：1/4"" - 4""(DN6-DN100)
工作压力(Work pressure)：1000psi
适用温度(Applicable temperature)：-40 < 180℃(PLL).
螺纹类型(Types of thread)：NPT BSPT BSP DIN259/2999
公称压力(Nominal pressure)：PN（Mpa）2.5 4.0 6.4
强度试验压力(Strength test pressure)：3.8 6.0 9.6
高密封试验压力(High pressure seal test pressure)：3.0 4.8 7.6
低压气密封试验压力(Low pressure seal test pressure)：0.6 0.6 0.6
适用介质（Applicable medium）：水、油品、气、硝酸类、醋酸类等（water oil gas acid）
|
| 性能规范 specifications |
|
|
|
| 公称压力 Nominal pressure |
PN |
1.6,2.5,4.0,6.5 |
Mpa |
| 强度试验压力 Strength testing pressure |
PN |
2.4,3.8,6.0,9.6 |
| 低压气密封试验压力 Seat testing pressure（low pressure） |
0.6 |
Mpa |
| 高压气密封试验压力 Seat testing pressure（high pressure |
1.8,2.8,4.4,7.1 |
| 适用介质 Applicable medium |
Q61F-(16-64)C 水、油、气WATER,oil，Gas |
Q61F-(16-64)P 硝酸类 Nitric acid |
Q61F-(16-64)R醋酸类 Acetic acid |
| 适用温度Applicable temperature |
（-40~180℃） | |
| |
| 主要零件材料 Materials of main parts |
| 零件名称 Description of parts |
Q61F-(16-64)C |
Q61F-(16-64)P |
Q61F-(16-64)R |
| 阀体 Body |
WCB |
ZG1Cr18Ni9TiCF8 |
ZG1Cr18Ni12Mo2TiCF8M |
| 球体 Ball |
1Cr18Ni9Ti304 |
1Cr18Ni9Ti304 |
1Cr18Ni12Mo2Ti316 |
| 阀杆 Stem |
1Cr18Ni9Ti304 |
1Cr18Ni9Ti304 |
1Cr18Ni12Mo2Ti316 |
| 密封圈Sealring |
聚四氟乙烯 Polyterafluoroethylene（PTFE) |
| 填料 Packing |
聚四氟乙烯 Polyterafluoroethylene（PTFE) | |
| |
| 主要外形尺寸 Main outer size |
| DN |
G |
|
L |
H |
W |
| 6 |
1/4″ |
|
65 |
52 |
105 |
| 10 |
3/8″ |
|
65 |
52 |
150 |
| 15 |
1/2″ |
|
70 |
65 |
130 |
| 20 |
3/4″ |
|
80 |
70 |
130 |
| 25 |
1″ |
|
90 |
78 |
150 |
| 32 |
1¼″ |
|
110 |
82 |
180 |
| 40 |
1½″ |
|
120 |
90 |
200 |
| 50 |
2″ |
|
140 |
98 |
200 |
| 65 |
2½″ |
|
160 |
140 |
240 | | |
|
|
|
|
